What do we need in an active optical cable?

The most important part of Active Optical Cable

Optical fiber

Multimode fiber for easy alignment (50 µm core)

Light source  (E => O)

High fiber coupling efficiency

Direct modulation

High efficiency, high reliability, high yield

In array form for multiple channels

Optical detector (O => E)

High speed

High reliability

Array format

Coupling optics

Array format

High coupling efficiency

Electronics

To control the light source and optical detector

VCSEL (Vertical Cavity Surface Emitting Laser)

The most important part of Active Optical Cable

PIN Photodiode

The most important part of Active Optical Cable

Coupling optical devices

The most important part of Active Optical Cable

Now can you get it clear of a active optical cable ? If you need more details information , contact www.smartavlink.com , you won’t feel disappointed . Smartavlink focused on active opticla cable for almost 7 years , have rich experience and technology on solving AOC problems , HDMI AOC , DP AOC , DVI AOC and now new coming Type C AOC , all have special solutions differentiating from markets . Smartavlink , welcome to discuss together .
